Features + Benefits
5in. x 30in. Stroke cylinder generates 37 tons of splitting force
Honda commercial GX390 series engine with cast iron cylinder sleeve and low oil shutdown
Hydraulic log lift makes splitting large logs easy
Premium hydraulic filtration ensures long lasting hydraulic component
Heavy duty I-Beam splitter design
Heavy-duty log cradles prevent logs from rolling off when split
Torsion suspension axle and light kit for high speed towing
Ultra-Tow Ultra-Pack high-speed hubs and 12in. wheels with high-speed tires
Adjustable leg and 2in. coupler
Log lift is driven by a 3in. bore x 12in. stroke hydraulic unit
Specification
Manufacture’s Warranty
48 months parts / 48 months labor
Ship Weight
1000.0 LB
Product Type
3-Point
Ram Force
37 Tons
Max. Log Diameter
24 in
Max. Log Length
31 in
Continuous Force
34.3 Tons
Engine Brand
Honda
Engine Model
GX390
Engine Displacement
390 cc
Cycle Time
13 sec
Tire Size
12 in
Splitter Orientation
Horizontal
Wheels
Yes
